Jupiter Video Wall Processors

J-Series Processors

HD/4K30 Outputs4 HD4 HD8 HD8 HD1220
4K60 Outputs610
HD Inputs14483256
4K Inputs11628
Multi-Wall System
Redundant PSU
Hot Swappable Boards
Warp/Blend Boards

Catalyst Processors

 CRS-5KCatalyst VCatalyst XL
PCIe slots0510-40
HD Outputs46464
4K60 Outputs11616
HD Inputs16156
4K Inputs16156
IP Decoding12100+1500+
Video Files121212+
Redundant PSU
Canvas Enabled


Easily visualize and control data that spans across multiple rooms, throughout a building or campus, or sprawled across an entire metropolitan area

  • 100% redundant AV over IP system
  • Integrated KVM
  • Unlimited video walls and displays
  • Unlimited 4K inputs & IP Streams
  • Web & VNC support


Powerful Collaborative Visualization Software for Operations Management, Anywhere

  • Web based, intuitive object-based, drag and drop interface
  • Supports both Active Directory and Workgroup environments for user authentication
  • Permission based access with identical views whether inside or outside of control room
  • Easily select streaming sources for sharing, annotate directly on live video and data, and control content from cameras, applications and web
  • Arrange video and data windows anywhere on display wall at any size
  • Justapose sources to get full 360-degree view of ops
  • Save preset scenes in advance for quick recall for specific situations, specific users, or time of day
  • Provides encrypted security and SSL authentication
